Könner & Söhnen Diesel Generator KS 9200HDES - 1/3 HD ATSR Silent
Voltage | 230/400 V |
Maximum power/Nominal power 230 V | 6.5/6.0 kW |
Maximum power/Nominal power 400 V | 7.5/7.0 kW |
Engine power | 18 hp |
Engine start | Electric |
Type of engine | Diesel |
Model of engine | KS 520HD |
Sockets | 1x32A(230V), 1x16A(400V) |
Fuel tank volume | 20 l |
Crankcase volume | 1.65 l |
Battery | 30 Ah |
Weight | 168 kg |
Frequency | 50 Hz |
Könner & Söhnen Diesel generator KS 9200HDES - 1/3 ATSR Silent (EURO V)
HIGH PERFORMANCE MOTOR
Every "Könner & Söhnen" motor has a power reserve. The high-performance engines of the "Könner & Söhnen" brand are sure to deliver the specified power! An automatic gain control (AVR) is used in Könner & Söhnen diesel generators. It ensures a constant output voltage of 230 V and is equipped with a short-circuit protection system.
VTS SYSTEM
Universal generators 2-in-1 feature a unique Voltage Transfer Switch (VTS) system that allows a generator to be used in both single-phase (230 V) and three-phase (400 V) modes with virtually no loss of power. Each mode has its own circuit breakers. It is not necessary to buy two separate generators for single-phase and three-phase loads.
ATS CONNECTION (not in scope of delivery)
The ATS unit (automatic transfer to emergency power) automatically starts the generator and transfers the load when the main power supply is interrupted, and automatically stops the generator when the main power supply is restored.
suitable ATS - KS 4/63
PREHEATER
All HEAVY DUTY diesel generators are equipped with a preheating function (PREHEATER), which allows you to start the generator effortlessly in winter.
HOUSING
The soundproof, vandal-proof housing effectively protects the generator in all seasons and extends its service life. The housing is equipped with handles and castors for easy handling.
TRANSPORT KIT
The generator housing is equipped with a four-wheeled transport kit to facilitate the movement of the unit.
USE IN THREE-PHASE GENERATOR MODE:
Diesel generators with VTS system in 3-phase 400V mode are not skew-load capable and must not be considered as a substitute for 3-phase outdoor mains. The house feed should be in 230V mode via the blue CEE socket. Such powerful electricity consumers as the electric cooker, instantaneous water heater, heating air heater, electric boiler or sauna are connected to 3-phase only for the purpose of load sharing and are in fact 230V electricity consumers that can be supplied as part of a 230V house feed-in, but not at full power.
Accessories can be purchased:
Automatic battery charger
User-friendly compact automatic battery charger for charging generator batteries.
The battery charger is protected against:
• Overheating
• Short circuit
• Reversed polarity
• Overcharging of the battery
KS EX3M-4S
Socket-adapter
KS CR-25M
Extension cable
Könner & Söhnen 10W-30
High quality semi-synthetic multigrade engine oil ULTRA Performace from "Könner & Söhnen" for petrol and diesel engines.
Additional parameters
Category: | Diesel |
---|---|
Weight: | 168 kg |
Spannung, V: | 230/400 |
Höchstleistung, kW: | 6.5 / 7.5 |
Nennleistung, kW: | 6.0 / 7.0 |
Frequenz, Hz: | 50 |
Strom, A (max): | 27.82 / 13.54 |
Steckdosen: | 1x16A (400V), 1x32A (230V) |
Laufzeit bei der Belastung 50%, h: | 11 |
LED-Anzeige: | Zähler Laufstunden, Frequenz, Spannung in Volt |
Geräuschpegel Lpa (7m)/Lwa, dB: | 69 / 94 |
Steckdose 12 V, А: | 12 / 8.3 |
Typ des Motors: | Diesel 1-Zylinder, 4-Takt mit Luftkühlung Viertakt |
Modell des Motors: | KS 520HD-V |
Ausgangsleistung, PS: | 18 |
Vorwärmungsfunktion: | + |
Volumen des Krafftstoffbehälters, l: | 20 |
Gehäusevolumen, l: | 1.65 |
Motorvolumen, cm3: | 498 |
Spannungsregler: | Intelligentes AVR-System |
Anlasser: | Elektro |
Batterie, Ah: | 30 |
ATS Anschluss: | + |
Abmessungen Netto (L*B*H), mm: | 900x545x905 |
Nettogewicht, kg: | 168 |
Schutzklasse: | IP23M |
Schieflastfähig: | Nein |
Kraftstoff: | DIESEL (kein Heizöl !!! ) |
